Shaped Wood Grain Wave Aluminum Square Tubes - Bent & Powder-Coated
| Place of Origin | Made in China |
|---|---|
| Brand Name | TianYuan |
| Certification | CE,ISO9000... |
| Model Number | TY-010 |
| Minimum Order Quantity | 1*20"container |
| Price | USD15.7/m2 |
| Packaging Details | 1pcs/PE packing /box /wood packing |
| Delivery Time | 15-20days |
| Payment Terms | L/C, T/T |
| Supply Ability | 9000M2/days |
Product Details
| Product Name | Curved Aluminum Square Tube | Product Thickness | 0.5-3.0mm (Customizable) |
|---|---|---|---|
| Product Color | All Colors Customizable | Application Scenarios | Indoor Ceilings Outdoor Curtain Walls |
| Highlight | wood grain aluminum square tubes,powder-coated aluminum curtain wall,bent aluminum square tubes |
||
Product Description
Shaped Wood Grain Wave Aluminum Square Tubes - Bent & Powder-Coated
Extruded Aluminum Square Tube Curtain Wall is an architectural facade cladding system composed of extruded aluminum alloy profiles arranged in regular patterns. With its lightweight strength, design flexibility, wind/earthquake resistance, and energy efficiency, this system has become a mainstream choice for modern architectural facades. Suitable for commercial complexes, public infrastructure, and high-end residences, it delivers both functional performance and unique aesthetic value.
Materials & Specifications
Alloy Selection
- Primary Alloys: 6063-T5 (preferred), 6061-T6, 3003 series
- Wall Thickness: ≥3.0mm for load-bearing parts; ≥1.2mm for non-load-bearing parts
Standard Specifications
| Parameter | Range | Common Values |
|---|---|---|
| Bottom Width | 10-300mm | 50-200mm |
| Height | 10-300mm | 40-200mm |
| Wall Thickness | 0.4-2.0mm | 1.0-1.5mm (outdoor use) |
| Length | 0-6m | 3-6m |
Custom extra-long or special-shaped profiles available for unique projects.
Surface Finishes
- Fluorocarbon Coating (preferred): 3-coat/3-bake process, film thickness ≥40μm, 20+ years weather resistance, self-cleaning
- Powder Coating: Cost-effective, wide color range, 10-15 years weather resistance
- Anodizing: High hardness (≥3H), wear-resistant, ideal for indoor or dry environments
- Wood Grain Transfer: Authentic wood texture, formaldehyde-free, suitable for nature-inspired designs
Product Specifications
| Product Name | Curved Aluminum Square Tube |
| Brand | Tianyuan |
| Product Thickness | 0.5-3.0mm (Customizable) |
| Product Color | All colors customizable |
| Product Material | Aluminum Alloy |
| Production Cycle | Approximately 5-10 days (Rush orders available) |
| Surface Treatment | Fluorocarbon paint, wood grain, stone grain, bamboo grain, polyester paint, powder coating (Customizable) |
| Product Advantages | Fire-resistant, weather-resistant, moisture-proof, eco-friendly, scratch-resistant, antibacterial |
| Product Processes | Perforation, engraving, openwork, arcing, double-curving, twisting, shaping, custom forms, painting, etc. |
Additional specifications, thicknesses, and shapes are customizable. For more details, please contact our online customer service.
Application Scenarios
Commercial Buildings
- Shopping malls, office building facades
- Hotel lobbies, entrance canopies
Public Buildings
- Airports, railway stations, hospital exteriors
- Pedestrian bridges, elevated walkways
Industrial & Residential
- Factory exterior sunshade systems
- Balcony partitions, courtyard railings
Comparison with Other Curtain Walls
vs. Aluminum Panel Curtain Walls
Square Tube Advantages: Lighter (3-8kg/sq.m vs. 9kg/sq.m), easier installation, better ventilation, 15-30% cost savings
Panel Advantages: Superior water tightness; ideal for high-moisture areas
Panel Advantages: Superior water tightness; ideal for high-moisture areas
vs. Glass Curtain Walls
Square Tube Advantages: Excellent sunshade, privacy protection, higher safety (no falling risks)
Glass Advantages: Better light transmission, maximum transparency
Glass Advantages: Better light transmission, maximum transparency
vs. Stone Curtain Walls
Square Tube Advantages: Lighter (reduces structural load), flexible designs, faster installation, 50%+ cost savings
Stone Advantages: Premium texture, exceptional durability
Stone Advantages: Premium texture, exceptional durability
