PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
| Place of Origin | Made in China |
|---|---|
| Brand Name | TianYuan |
| Certification | CE,ISO9000... |
| Model Number | TY-010 |
| Minimum Order Quantity | 1*20"container |
| Price | USD15.7/m2 |
| Packaging Details | 1pcs/PE packing /box /wood packing |
| Delivery Time | 15-20days |
| Payment Terms | L/C, T/T |
| Supply Ability | 9000M2/days |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Curved Aluminum Square Tube | Product Thickness | 0.5-3.0mm (Customizable) |
|---|---|---|---|
| Product Color | All Colors Customizable | Application Scenarios | Indoor Ceilings Outdoor Curtain Walls |
Product Description
With its comprehensive advantages of lightweight strength, durability, versatile design, safety, and environmental friendliness, aluminum veneer has become the preferred material for modern commercial storefronts. Whether for chain enterprises seeking brand consistency or independent shops aiming for a unique identity, aluminum veneer provides a complete solution from design to installation. It not only enhances storefront aesthetics but also reduces long-term maintenance costs, creating sustained value for businesses.
Product Specifications
| Parameter | Specification Range | Recommended Configuration for Storefronts | |
|---|---|---|---|
| Panel Thickness | 1.5mm, 2.0mm, 2.5mm, 3.0mm | ≥2.0mm for outdoor use; ≥3.0mm for large storefronts | |
| Standard Size | Width: 1220mm, 1524mm; Length: ≤6000mm | 1220×2440mm (4×8ft) – most commonly used | |
| Bending Radius | ≥1.5×panel thickness | R=5mm for curved storefronts | |
| Reinforcement Ribs | Thickness: 2.0-3.0mm; Spacing: 300-500mm | Mandatory for storefronts ≥1.5m in height; 400mm spacing |
2. Surface Treatments (Three Main Processes)
PVDF Coating
Three-coat one-bake process with total thickness ≥70μm; exceptional weather resistance, maintaining color fastness for 15-20 years outdoors without fading.
Resistant to acid rain, salt spray, and UV rays; surface hardness reaches 6H, featuring easy cleaning and self-cleaning properties.
Suitable for high-end commercial projects, coastal areas, and long-term outdoor applications (higher cost).
Powder Coating
- Electrostatic spraying process with thickness ≥60μm; vibrant colors, strong adhesion, and solvent-free environmental friendliness.
- Maintains performance for over 10 years indoors and 5-8 years outdoors, offering high cost-effectiveness.
- Ideal for indoor storefronts, mall shops, and budget-constrained projects.
Anodizing
Forms a hard oxide film (thickness: 8-25μm) with a strong metallic finish, hardness comparable to stainless steel.
Scratch-resistant and acid-alkali resistant, perfect for industrial-style designs and humid environments.
No additional coating required; simple maintenance, cost-effective between PVDF and powder coating.
Application Scenarios: A Versatile Solution for Commercial Entrances
1. Mainstream Applications (By Building Type)
Brand Chain Stores (Catering, Retail, Apparel, Cosmetics)
Advantages: Standardized production ensures consistent brand image across national stores; fast installation supports brand expansion.
Examples: Curved storefronts for milk tea shops, custom perforated designs for clothing stores, minimalist flat panels for convenience stores.
High-End Commercial Buildings & Office Towers
Advantages: Custom shapes enhance commercial space quality; PVDF coating delivers premium, long-lasting texture.
Examples: Large curved surfaces for shopping mall main entrances, metallic-finish storefronts for office lobbies.
Public Building Entrances (Banks, Hospitals, Schools)
Advantages: Fire-safe, easy to clean and maintain, complying with public building regulations.
Examples: Elegant facades for bank branches, prominent signage for hospital entrances, modern designs for school gates.
2. Specialized Scenario Solutions
Coastal Areas: 5052-H32 alloy + PVDF coating resists salt spray erosion, extending service life by 30%.
Northern Frigid Regions: 6061-T6 alloy with excellent toughness, resistant to freezing cracks and snow loads.
High-Foot Traffic Areas: Surface-hardened treatment for impact resistance; daily cleaning requires only water.
Creative Design Needs: Laser cutting + bending processes to achieve any shape (e.g., 3D brand logo designs).
